Description
Otowave 102 Screening Tympanometry – Product Description
The Otowave 102 Screening Tympanometry is a compact, highly reliable handheld device designed for quick and accurate assessment of middle ear function. It is widely used by audiologists, ENT specialists, hearing care centers, hospitals, and mobile screening teams, offering excellent portability with advanced tympanometry performance.
With its ergonomic handheld structure, real-time graphical display, and automated test analysis, the device is especially effective for screening both children and adults for common middle ear conditions such as otitis media (glue ear), Eustachian tube dysfunction, and conductive hearing loss.
Key Features
- Fast and accurate middle ear measurement
- Lightweight, portable handheld design
- Large LCD graphical display for clear visualization
- Automatic Pass/Refer result evaluation
- Programmable ipsilateral acoustic reflex testing
- Built-in memory for patient data storage
- PC connectivity with NOAH-compatible data transfer
- Optional portable printer and infrared data transfer
- Multi-language support
- Ergonomic design for comfortable clinical use
Technical Specifications
- Probe Tone: 226 Hz ±2%
- Pressure Range: +200 daPa to -400 daPa
- Ear Canal Volume Range: 0.2 ml to 5 ml
- Reflex Test Frequencies:
- 102-1: 1 kHz
- 102-4: 500 Hz, 1 kHz, 2 kHz, 4 kHz
- Power Supply: 4 AA alkaline or rechargeable NiMH batteries
- Weight: Approx. 380 g
- Internal Memory: Up to 30 patient records
Clinical Applications
The Otowave 102 is commonly used for:
- Middle ear screening
- Tympanometry testing
- Acoustic reflex assessment
- Pediatric hearing evaluation
- School and community screening programs
- ENT and audiology clinics
- Mobile hearing care services
Benefits
The Otowave 102 enhances clinical efficiency by combining fast testing with dependable results. Its lightweight design supports easy mobility, while built-in memory and optional PC connectivity streamline patient data management and workflow. It is an ideal solution for clinicians seeking accuracy, speed, and convenience in middle ear diagnostics.
